Paulin® 126-553 Partial Threaded Serrated Flange Bolt, 3/8-16, 1-1/2 in L Under Head, 5 Grade, Yellow Zinc Dichromate Coated
Paulin® 126-553 Partial Threaded Serrated Flange Bolt, 3/8-16, 1-1/2 in L Under Head, 5 Grade, Yellow Zinc Dichromate Coated
SKU: TKJ379
Manufacturer Part Number: 126-553
EAN: 0622412278169
Brand: Paulin®
Description
Specifications
| Diameter - Thread Size | 3/8-16 |
| Finish | Yellow Zinc Dichromate Coated |
| Grade | 5 |
| Hardness | C25-C34 Rockwell |
| Head Size | 9/16 in W |
| Head Type | Hex |
| Length Under Head | 1-1/2 in |
| Material | Carbon Steel |
| Measurement System | Imperial |
| Series | 126 Series |
| Tensile Strength | 12000 psi |
| Thread Type | UNC |
| Type | Partial Threaded Serrated |
Warranty: 2 years
Features
- Grade 5 is identified with three radial bars head markings
- Quenched and tempered for higher tensile strength and holding power
- Features a built-in washer-like flange just beneath the head, providing a wide area for distributing the load
- Full thread (FT)
- 9/16 in Across Flats (W)
- 25/64 in Height
