Gates® Power Transmission PowerGrip® GT®2 P72-8MGT-12 Synchronous Sprocket, 1/2 to 1-11/16 in Taper-Lock® Bore, 7.16 in OD, 72 Grooves, 7.218 in Dia Pitch, 0.85 in W Face


Description

Gates® Power Transmission PowerGrip® GT®2 Synchronous Sprocket, Series: 7708, Taper-Lock® Bore, 1/2 to 1-11/16 in Bore Dia, 7.16 in Outside Dia, 7.218 in, 72 Grooves, 8 mm Pitch, 0.85 in Face Width, 7-1/2 in Flange Dia, 3.63 in Hub Dia, 1610 Bushing, 1 in Overall Length, For Use With: 12 mm W PowerGrip® GT®3 and PowerGrip® GT®2 Belts, Ductile Iron

PowerGrip Sprockets and Pulleys provide optimum performance for all constructions of PowerGrip GT, PowerGrip HTD and PowerGrip Timing belts, delivering maximum performance and superior reliability. PowerGrip sprockets are precision manufactured and static balanced to eliminate sprocket wobble.

Specifications

Bore Diameter 1/2 to 1-11/16 in
Bore Type Taper-Lock®
Bushing Type 1610
Face Width 0.85 in
Flange Diameter 7-1/2 in
Hub Diameter 3.63 in
Material Ductile Iron
Number of Grooves 72
Outside Diameter 7.16 in
Overall Length 1 in
Pitch 8 mm
Pitch Diameter 7.218 in
Series 7708
Suitable For Use With 12 mm W PowerGrip® GT®3 and PowerGrip® GT®2 Belts

Country of Origin: United States

Features

  • Full split in bushing allows easy installation and removal
  • Precise sprocket design produces positive, press fit to shaft
  • Precision manufactured and static balanced
  • Smaller, narrower sprockets save shaft space, keep the load closer to bearing and extend life of reducer
