3M™ 3M 9324 1.25" x 36yd High Tack Squeak Reduction Tape, 36 yd L x 1-1/4 in W, 6.5 mil THK, Acrylic Adhesive, UHMWP Backing, Clear

Description
3M™ Squeak Reduction Tape, High Tack, Series: 9324, 36 yd Length, 1-1/4 in Width, 6.5 mil Thickness, Clear, Acrylic Adhesive, UHMWP Backing, 75 in-oz Adhesion Strength, 40 in-lb Tensile Strength, 225 deg F Maximum Operating, -30 deg F Minimum Operating, Resistance Properties: Abrasion and Chemical, Specifications Met: ASTM D3330, ASTM D3759, ASTM D3562
3M™ 9324 squeak reduction tape is a black UHMW polyethylene tape often used help control squeaks and rattles due to vibration or wear of metal and plastic materials. The thin tape creates a "slip plane" effect to allow contact without wear. Squeak reduction tape has outstanding abrasion resistance and will outwear PTFE and other materials in sliding applications. High tack acrylic adhesive provides strong initial bond and excellent adhesion to many painted metal and plastic surfaces. 3M™ 5430 is highly used in the automotive and industrial industries. UHMW tape is ideal in applications where lubrication is not possible because of contamination. Long lasting, low maintenance, use on automotive instrument panels and interiors to help control squeaks and rattles due to vibration or wear of metals, plastics and dissimilar materials. Works well to reduce noise between rim fascia and painted metal. Ideal to reduce automobile and commercial vehicle door squeaks and rattles. Use in the industrial, manufacturing and distribution industries to protect plastic and metal chutes, conveyors and guide rails from wear; corrugated boxes, parts and materials slide more easily on surfaces lined with slick UHMW PE tape. Protect containers from wear and damage, use UHMW tape as an easy release liner for tank and bin liners. Ideal for many impact wear and sliding applications, apply for easy glide of drawer slides and cabinets providing smooth, friction-free movement. High tack adhesion to many painted metal and plastic surfaces.
Specifications
| Adhesion Strength | 75 in-oz |
| Adhesive Material | Acrylic |
| Backing Material | UHMWP |
| Color | Clear |
| Length | 36 yd |
| Maximum Operating Temperature | 225 deg F |
| Minimum Operating Temperature | -30 deg F |
| Resistance Properties | Abrasion and Chemical |
| Series | 9324 |
| Specifications Met | ASTM D3330, ASTM D3759, ASTM D3562 |
| Tensile Strength | 40 in-lb |
| Thickness | 6.5 mil |
| Type | High Tack |
| Width | 1-1/4 in |
Country of Origin: United States
Standards and Approvals: ASTM D3330, ASTM D3759, ASTM D3652
Application:
Automotive instrument panel and interior noise reduction, noise reduction between rim fascia and painted metal, noise reduction on doors and industrial sliding or wear applications requiring very high adhesion
Features
- 6.5 mil THK, black UHMW PE film with a high tack acrylic adhesive
- Long lasting, abrasion and chemical-resistant
- Low coefficient of friction for applications requiring slick surfaces
- Help control squeaks and rattles due to vibration and wear
- Anti-stick for easy release of many inks, adhesives and other sticky materials
- Self-lubricating, use where lubrication is not possible because of contamination
- Prevents marking or scratching of a product or part
